C42GM LTE Cat M1/Cat NB2/NB1 IoT Module


C42GM is Cavli’s all-new NarrowBand-Internet of Things (NB-IoT) platform, based on low power wide area networks (LPWAN). This LTE Cat M1/Cat NB2/NB1 module, which adheres to 3GPP Release 14 specifications, measures 26.5 x 22.5 x 2.3 mm. Such a compact design enables the module to meet ultra-low power consumption standards.

Furthermore, the C42GM has a plethora of interfaces on offer that ensure flexibility in its operational connectivity. It also offers global band support, ensuring compatibility in various regions. The module offers integrated GNSS for accurate tracking capabilities and includes an integrated eSIM, which is powered by the Cavli Hubble Global Connectivity and Device Management Platform. Its adaptability makes it well-suited for various applications, including asset tracking, vehicle telemetry systems, smart cities, healthcare, smart homes, retail, safety devices, as well as industrial and agricultural intelligent monitoring.

Key highlights

Integrated Hubble eSIM

Integrated Hubble eSIM

Powered by Cavli Hubble

Powered by Cavli Hubble

Applicable regions - (Global)

Applicable regions - (Global)

CAN Bus Support

CAN Bus (Classic) Support

GNSS Support

GNSS Support

Sigfox Support

Sigfox Support

Cat-M1/NB-IoT

Cat-M1/NB-IoT

low power Consumption

Low Power Consumption

USB 2.0 Interface

USB 2.0 Interface

Available Form-Factors

LGA

LGA

Mini PCI

Mini PCI

Technical data

Cellular Bands Supported

M1 / NB1 / NB2 Bands -B1/ B2/ B3/ B4/ B5/ B6/ B8/ B9/ B10/ B12/ B13/ B14/ B15/ B16/ B17/ B18/ B19/ B20/ B24/ B25/B26/ B27/ B28/ B39/ B54/ B65/B66/ B68/ B71/ B90

Supported Location Services

GPS/ BeiDou

OS

Zephyr RTOS

Auxiliary Connectivity

Sigfox

Cellular Connectivity Download & Uplink Speed (* Peak Values)

LTE-M1 : 1119Kbps (UL), 588Kbps (DL)

NB1 : 60Kbps (UL), 20Kbps (DL)

NB2 : 158.5Kbps (UL), 127Kbps (DL)

Packaging

Dimension : 26.5 x 22.5 x 2.3 mm, LGA Package

Interfaces

USB 2.0 - x1, JTAG - x1, 8xGPIO**, 1xI2C**, 2xADC**, 1xUSIM, 1xSPI**, 3xUART, 1xANT , 1xGNSS_ANT*, 1xSDIO, 1xCAN Bus, 1xPCM**

*Optional feature    |   **Requires SDK

Pin compatibility

Applicable industries

Automotive Logistics

Automotive & Logistics

Agriculture

Agriculture

Health Care

Health Care &
E-Health

Retail

Retail

Smart Home

Smart Home

Smart City

Smart City

Energy Utilities

Energy & Utilities

Safety Security

Safety & Security

Manufacturing

Manufacturing

Available variants

Modules/mPCIe Technology Flash (MB) GNSS Internal Hubble eSIM
C42GM-N16S0N Technology NB-IoT Flash (MB) 16 GNSS No Internal Hubble eSIM No
C42GM-N16S0H Technology NB-IoT Flash (MB) 16 GNSS No Internal Hubble eSIM Yes
C42GM-M16S0N Technology LTE-M Flash (MB) 16 GNSS No Internal Hubble eSIM No
C42GM-M16S0H Technology LTE-M Flash (MB) 16 GNSS No Internal Hubble eSIM Yes
C42GM-N16GNN Technology NB-IoT Flash (MB) 16 GNSS Yes Internal Hubble eSIM No
C42GM-N16GNH Technology NB-IoT Flash (MB) 16 GNSS Yes Internal Hubble eSIM Yes
C42GM-M16GNN Technology LTE-M Flash (MB) 16 GNSS Yes Internal Hubble eSIM No
C42GM-M16GNH Technology LTE-M Flash (MB) 16 GNSS Yes Internal Hubble eSIM Yes
C42GM-N32S0N Technology NB-IoT Flash (MB) 32 GNSS No Internal Hubble eSIM No
C42GM-N32S0H Technology NB-IoT Flash (MB) 32 GNSS No Internal Hubble eSIM Yes
C42GM-M32S0N Technology LTE-M Flash (MB) 32 GNSS No Internal Hubble eSIM No
C42GM-M32S0H Technology LTE-M Flash (MB) 32 GNSS No Internal Hubble eSIM Yes
C42GM-N32GNN Technology NB-IoT Flash (MB) 32 GNSS Yes Internal Hubble eSIM No
C42GM-N32GNH Technology NB-IoT Flash (MB) 32 GNSS Yes Internal Hubble eSIM Yes
C42GM-M32GNN Technology LTE-M Flash (MB) 32 GNSS Yes Internal Hubble eSIM No
C42GM-M32GNH Technology LTE-M Flash (MB) 32 GNSS Yes Internal Hubble eSIM Yes
